Android Firebase | Android Push Notifications using Firebase Cloud Messaging FCM

Hello Friends,
               Google moved from Google Cloud Messaging (GCM) to Firebase Cloud Messaging (FCM). Just like GCM, FCM is a cross-platform messaging solution that allows you to send messages. FCM is completely free and there are no limitations.

• Firebase Message types : Using FCM you can send three types of messages i.e:
• Notification Message
• Data Message
• both Notification & Data Payload

• Integrating Firebase Cloud Messaging
• First thing you need to do is go to https://firebase.google.com/ and make an account to gain access to their console. After you gain access to the console you can start by creating your first project.
• Give the package name of your project in which you are going to integrate the Firebase. Here the google-services.json file will be downloaded when you press add app button.

• Sending Messages from Firebase Console : Go to firebase console(https://console.firebase.google.com/project/fir-notification-d7287/notification) and click on Notifications in left menu. You will get an interface where you can type the message, select the targeting and send the message.



1. MainActivity.java

view plainprint?

1. package android.developer.solutions.firebasenotification.activity;
2.
3. import android.content.BroadcastReceiver;
4. import android.content.Context;
5. import android.content.Intent;
6. import android.content.IntentFilter;
7. import android.content.SharedPreferences;
8. import android.developer.solutions.firebasenotification.R;
9. import android.developer.solutions.firebasenotification.app.Config;
10. import android.developer.solutions.firebasenotification.util.NotificationUtils;
11. import android.os.Bundle;
12. import android.support.v4.content.LocalBroadcastManager;
13. import android.support.v7.app.AppCompatActivity;
14. import android.text.TextUtils;
15. import android.util.Log;
16. import android.widget.TextView;
17. import android.widget.Toast;
18.
19. import com.google.firebase.messaging.FirebaseMessaging;
20.
21. public class MainActivity extends AppCompatActivity {
22.
23.     private static final String TAG = MainActivity.class.getSimpleName();
24.     private BroadcastReceiver mRegistrationBroadcastReceiver;
25.     private TextView txtRegId, txtMessage;
26.
27.     @Override
28.     protected void onCreate(Bundle savedInstanceState) {
29.         super.onCreate(savedInstanceState);
30.         setContentView(R.layout.activity_main);
31.
32.         txtRegId = (TextView) findViewById(R.id.txt_reg_id);
33.         txtMessage = (TextView) findViewById(R.id.txt_push_message);
34.
35.         mRegistrationBroadcastReceiver = new BroadcastReceiver() {
36.             @Override
37.             public void onReceive(Context context, Intent intent) {
38.
39.                 // checking for type intent filter
40.                 if (intent.getAction().equals(Config.REGISTRATION_COMPLETE)) {
41.                     // gcm successfully registered
42.                     // now subscribe to global` topic to receive app wide notifications
43.                     FirebaseMessaging.getInstance().subscribeToTopic(Config.TOPIC_GLOBAL);
44.
45.                     displayFirebaseRegId();
46.
47.                 } else if (intent.getAction().equals(Config.PUSH_NOTIFICATION)) {
48.                     // new push notification is received
49.
50.                     String message = intent.getStringExtra("message");
51.                     Toast.makeText(getApplicationContext(), "Push notification: " + message, Toast.LENGTH_LONG).show();
52.                     txtMessage.setText(message);
53.                 }
54.             }
55.         };
56.
57.         displayFirebaseRegId();
58.     }
59.
60.     // Fetches reg id from shared preferences
61.     // and displays on the screen
62.     private void displayFirebaseRegId() {
63.         SharedPreferences pref = getApplicationContext().getSharedPreferences(Config.SHARED_PREF, 0);
64.         String regId = pref.getString("regId", null);
65.
66.         Log.e(TAG, "Firebase reg id: " + regId);
67.
68.         if (!TextUtils.isEmpty(regId))
69.             txtRegId.setText("Firebase Reg Id: " + regId);
70.         else
71.             txtRegId.setText("Firebase Reg Id is not received yet!");
72.     }
73.
74.     @Override
75.     protected void onResume() {
76.         super.onResume();
77.
78.         // register GCM registration complete receiver
79. //        LocalBroadcastManager.getInstance(this).registerReceiver(mRegistrationBroadcastReceiver,
80. //                new IntentFilter(Config.REGISTRATION_COMPLETE));
81.
82.         // register new push message receiver
83.         // by doing this, the activity will be notified each time a new message arrives
84.         LocalBroadcastManager.getInstance(this).registerReceiver(mRegistrationBroadcastReceiver,
85.                 new IntentFilter(Config.PUSH_NOTIFICATION));
86.
87.         // clear the notification area when the app is opened
88.         NotificationUtils.clearNotifications(getApplicationContext());
89.     }
90.
91.     @Override
92.     protected void onPause() {
93.         LocalBroadcastManager.getInstance(this).unregisterReceiver(mRegistrationBroadcastReceiver);
94.         super.onPause();
95.     }
96. }

package android.developer.solutions.firebasenotification.activity;

import android.content.BroadcastReceiver;
import android.content.Context;
import android.content.Intent;
import android.content.IntentFilter;
import android.content.SharedPreferences;
import android.developer.solutions.firebasenotification.R;
import android.developer.solutions.firebasenotification.app.Config;
import android.developer.solutions.firebasenotification.util.NotificationUtils;
import android.os.Bundle;
import android.support.v4.content.LocalBroadcastManager;
import android.support.v7.app.AppCompatActivity;
import android.text.TextUtils;
import android.util.Log;
import android.widget.TextView;
import android.widget.Toast;

import com.google.firebase.messaging.FirebaseMessaging;

public class MainActivity extends AppCompatActivity {

    private static final String TAG = MainActivity.class.getSimpleName();
    private BroadcastReceiver mRegistrationBroadcastReceiver;
    private TextView txtRegId, txtMessage;

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        txtRegId = (TextView) findViewById(R.id.txt_reg_id);
        txtMessage = (TextView) findViewById(R.id.txt_push_message);

        mRegistrationBroadcastReceiver = new BroadcastReceiver() {
            @Override
            public void onReceive(Context context, Intent intent) {

                // checking for type intent filter
                if (intent.getAction().equals(Config.REGISTRATION_COMPLETE)) {
                    // gcm successfully registered
                    // now subscribe to global` topic to receive app wide notifications
                    FirebaseMessaging.getInstance().subscribeToTopic(Config.TOPIC_GLOBAL);

                    displayFirebaseRegId();

                } else if (intent.getAction().equals(Config.PUSH_NOTIFICATION)) {
                    // new push notification is received

                    String message = intent.getStringExtra("message");
                    Toast.makeText(getApplicationContext(), "Push notification: " + message, Toast.LENGTH_LONG).show();
                    txtMessage.setText(message);
                }
            }
        };

        displayFirebaseRegId();
    }

    // Fetches reg id from shared preferences
    // and displays on the screen
    private void displayFirebaseRegId() {
        SharedPreferences pref = getApplicationContext().getSharedPreferences(Config.SHARED_PREF, 0);
        String regId = pref.getString("regId", null);

        Log.e(TAG, "Firebase reg id: " + regId);

        if (!TextUtils.isEmpty(regId))
            txtRegId.setText("Firebase Reg Id: " + regId);
        else
            txtRegId.setText("Firebase Reg Id is not received yet!");
    }

    @Override
    protected void onResume() {
        super.onResume();

        // register GCM registration complete receiver
//        LocalBroadcastManager.getInstance(this).registerReceiver(mRegistrationBroadcastReceiver,
//                new IntentFilter(Config.REGISTRATION_COMPLETE));

        // register new push message receiver
        // by doing this, the activity will be notified each time a new message arrives
        LocalBroadcastManager.getInstance(this).registerReceiver(mRegistrationBroadcastReceiver,
                new IntentFilter(Config.PUSH_NOTIFICATION));

        // clear the notification area when the app is opened
        NotificationUtils.clearNotifications(getApplicationContext());
    }

    @Override
    protected void onPause() {
        LocalBroadcastManager.getInstance(this).unregisterReceiver(mRegistrationBroadcastReceiver);
        super.onPause();
    }
}

2. MyFirebaseInstanceIDService.java

view plainprint?

1. package android.developer.solutions.firebasenotification.service;
2.
3. import android.content.Intent;
4. import android.content.SharedPreferences;
5. import android.developer.solutions.firebasenotification.app.Config;
6. import android.support.v4.content.LocalBroadcastManager;
7. import android.util.Log;
8.
9. import com.google.firebase.iid.FirebaseInstanceId;
10. import com.google.firebase.iid.FirebaseInstanceIdService;
11.
12.
13. /**
14.  * Created by Mukesh on 10/02/17.
15.  * www.androiddevelopersolutions.com/
16.  */
17. public class MyFirebaseInstanceIDService extends FirebaseInstanceIdService {
18.     private static final String TAG = MyFirebaseInstanceIDService.class.getSimpleName();
19.
20.     @Override
21.     public void onTokenRefresh() {
22.         super.onTokenRefresh();
23.         String refreshedToken = FirebaseInstanceId.getInstance().getToken();
24.
25.         // Saving reg id to shared preferences
26.         storeRegIdInPref(refreshedToken);
27.
28.         // sending reg id to your server
29.         sendRegistrationToServer(refreshedToken);
30.
31.         // Notify UI that registration has completed, so the progress indicator can be hidden.
32.         Intent registrationComplete = new Intent(Config.REGISTRATION_COMPLETE);
33.         registrationComplete.putExtra("token", refreshedToken);
34.         LocalBroadcastManager.getInstance(this).sendBroadcast(registrationComplete);
35.     }
36.
37.     private void sendRegistrationToServer(final String token) {
38.         // sending gcm token to server
39.         Log.e(TAG, "sendRegistrationToServer: " + token);
40.     }
41.
42.     private void storeRegIdInPref(String token) {
43.         SharedPreferences pref = getApplicationContext().getSharedPreferences(Config.SHARED_PREF, 0);
44.         SharedPreferences.Editor editor = pref.edit();
45.         editor.putString("regId", token);
46.         editor.commit();
47.     }
48. }

package android.developer.solutions.firebasenotification.service;

import android.content.Intent;
import android.content.SharedPreferences;
import android.developer.solutions.firebasenotification.app.Config;
import android.support.v4.content.LocalBroadcastManager;
import android.util.Log;

import com.google.firebase.iid.FirebaseInstanceId;
import com.google.firebase.iid.FirebaseInstanceIdService;


/**
 * Created by Mukesh on 10/02/17.
 * www.androiddevelopersolutions.com/
 */
public class MyFirebaseInstanceIDService extends FirebaseInstanceIdService {
    private static final String TAG = MyFirebaseInstanceIDService.class.getSimpleName();

    @Override
    public void onTokenRefresh() {
        super.onTokenRefresh();
        String refreshedToken = FirebaseInstanceId.getInstance().getToken();

        // Saving reg id to shared preferences
        storeRegIdInPref(refreshedToken);

        // sending reg id to your server
        sendRegistrationToServer(refreshedToken);

        // Notify UI that registration has completed, so the progress indicator can be hidden.
        Intent registrationComplete = new Intent(Config.REGISTRATION_COMPLETE);
        registrationComplete.putExtra("token", refreshedToken);
        LocalBroadcastManager.getInstance(this).sendBroadcast(registrationComplete);
    }

    private void sendRegistrationToServer(final String token) {
        // sending gcm token to server
        Log.e(TAG, "sendRegistrationToServer: " + token);
    }

    private void storeRegIdInPref(String token) {
        SharedPreferences pref = getApplicationContext().getSharedPreferences(Config.SHARED_PREF, 0);
        SharedPreferences.Editor editor = pref.edit();
        editor.putString("regId", token);
        editor.commit();
    }
}

3. MyFirebaseMessagingService.java

view plainprint?

1. package android.developer.solutions.firebasenotification.service;
2.
3. import android.content.Context;
4. import android.content.Intent;
5. import android.developer.solutions.firebasenotification.activity.MainActivity;
6. import android.developer.solutions.firebasenotification.app.Config;
7. import android.developer.solutions.firebasenotification.util.NotificationUtils;
8. import android.support.v4.content.LocalBroadcastManager;
9. import android.text.TextUtils;
10. import android.util.Log;
11.
12. import com.google.firebase.messaging.FirebaseMessagingService;
13. import com.google.firebase.messaging.RemoteMessage;
14.
15. import org.json.JSONException;
16. import org.json.JSONObject;
17.
18.
19. /**
20.  * Created by Mukesh on 10/02/17.
21.  * www.androiddevelopersolutions.com/
22.  */
23. public class MyFirebaseMessagingService extends FirebaseMessagingService {
24.
25.     private static final String TAG = MyFirebaseMessagingService.class.getSimpleName();
26.
27.     private NotificationUtils notificationUtils;
28.
29.     @Override
30.     public void onMessageReceived(RemoteMessage remoteMessage) {
31.         Log.e(TAG, "From: " + remoteMessage.getFrom());
32.
33.         if (remoteMessage == null)
34.             return;
35.
36.         // Check if message contains a notification payload.
37.         if (remoteMessage.getNotification() != null) {
38.             Log.e(TAG, "Notification Body: " + remoteMessage.getNotification().getBody());
39.             handleNotification(remoteMessage.getNotification().getBody());
40.         }
41.
42.         // Check if message contains a data payload.
43.         if (remoteMessage.getData().size() > 0) {
44.             Log.e(TAG, "Data Payload: " + remoteMessage.getData().toString());
45.
46.             try {
47.                 JSONObject json = new JSONObject(remoteMessage.getData().toString());
48.                 handleDataMessage(json);
49.             } catch (Exception e) {
50.                 Log.e(TAG, "Exception: " + e.getMessage());
51.             }
52.         }
53.     }
54.
55.     private void handleNotification(String message) {
56.         if (!NotificationUtils.isAppIsInBackground(getApplicationContext())) {
57.             // app is in foreground, broadcast the push message
58.             Intent pushNotification = new Intent(Config.PUSH_NOTIFICATION);
59.             pushNotification.putExtra("message", message);
60.             LocalBroadcastManager.getInstance(this).sendBroadcast(pushNotification);
61.
62.             // play notification sound
63.             NotificationUtils notificationUtils = new NotificationUtils(getApplicationContext());
64.             notificationUtils.playNotificationSound();
65.         } else {
66.             // If the app is in background, firebase itself handles the notification
67.         }
68.     }
69.
70.     private void handleDataMessage(JSONObject json) {
71.         Log.e(TAG, "push json: " + json.toString());
72.
73.         try {
74.             JSONObject data = json.getJSONObject("data");
75.
76.             String title = data.getString("title");
77.             String message = data.getString("message");
78.             boolean isBackground = data.getBoolean("is_background");
79.             String imageUrl = data.getString("image");
80.             String timestamp = data.getString("timestamp");
81.             JSONObject payload = data.getJSONObject("payload");
82.
83.             Log.e(TAG, "title: " + title);
84.             Log.e(TAG, "message: " + message);
85.             Log.e(TAG, "isBackground: " + isBackground);
86.             Log.e(TAG, "payload: " + payload.toString());
87.             Log.e(TAG, "imageUrl: " + imageUrl);
88.             Log.e(TAG, "timestamp: " + timestamp);
89.
90.
91.             if (!NotificationUtils.isAppIsInBackground(getApplicationContext())) {
92.                 // app is in foreground, broadcast the push message
93.                 Intent pushNotification = new Intent(Config.PUSH_NOTIFICATION);
94.                 pushNotification.putExtra("message", message);
95.                 LocalBroadcastManager.getInstance(this).sendBroadcast(pushNotification);
96.
97.                 // play notification sound
98.                 NotificationUtils notificationUtils = new NotificationUtils(getApplicationContext());
99.                 notificationUtils.playNotificationSound();
100.             } else {
101.                 // app is in background, show the notification in notification tray
102.                 Intent resultIntent = new Intent(getApplicationContext(), MainActivity.class);
103.                 resultIntent.putExtra("message", message);
104.
105.                 // check for image attachment
106.                 if (TextUtils.isEmpty(imageUrl)) {
107.                     showNotificationMessage(getApplicationContext(), title, message, timestamp, resultIntent);
108.                 } else {
109.                     // image is present, show notification with image
110.                     showNotificationMessageWithBigImage(getApplicationContext(), title, message, timestamp, resultIntent, imageUrl);
111.                 }
112.             }
113.         } catch (JSONException e) {
114.             Log.e(TAG, "Json Exception: " + e.getMessage());
115.         } catch (Exception e) {
116.             Log.e(TAG, "Exception: " + e.getMessage());
117.         }
118.     }
119.
120.     /**
121.      * Showing notification with text only
122.      */
123.     private void showNotificationMessage(Context context, String title, String message, String timeStamp, Intent intent) {
124.         notificationUtils = new NotificationUtils(context);
125.         intent.setFlags(Intent.FLAG_ACTIVITY_NEW_TASK | Intent.FLAG_ACTIVITY_CLEAR_TASK);
126.         notificationUtils.showNotificationMessage(title, message, timeStamp, intent);
127.     }
128.
129.     /**
130.      * Showing notification with text and image
131.      */
132.     private void showNotificationMessageWithBigImage(Context context, String title, String message, String timeStamp, Intent intent, String imageUrl) {
133.         notificationUtils = new NotificationUtils(context);
134.         intent.setFlags(Intent.FLAG_ACTIVITY_NEW_TASK | Intent.FLAG_ACTIVITY_CLEAR_TASK);
135.         notificationUtils.showNotificationMessage(title, message, timeStamp, intent, imageUrl);
136.     }
137. }

package android.developer.solutions.firebasenotification.service;

import android.content.Context;
import android.content.Intent;
import android.developer.solutions.firebasenotification.activity.MainActivity;
import android.developer.solutions.firebasenotification.app.Config;
import android.developer.solutions.firebasenotification.util.NotificationUtils;
import android.support.v4.content.LocalBroadcastManager;
import android.text.TextUtils;
import android.util.Log;

import com.google.firebase.messaging.FirebaseMessagingService;
import com.google.firebase.messaging.RemoteMessage;

import org.json.JSONException;
import org.json.JSONObject;


/**
 * Created by Mukesh on 10/02/17.
 * www.androiddevelopersolutions.com/
 */
public class MyFirebaseMessagingService extends FirebaseMessagingService {

    private static final String TAG = MyFirebaseMessagingService.class.getSimpleName();

    private NotificationUtils notificationUtils;

    @Override
    public void onMessageReceived(RemoteMessage remoteMessage) {
        Log.e(TAG, "From: " + remoteMessage.getFrom());

        if (remoteMessage == null)
            return;

        // Check if message contains a notification payload.
        if (remoteMessage.getNotification() != null) {
            Log.e(TAG, "Notification Body: " + remoteMessage.getNotification().getBody());
            handleNotification(remoteMessage.getNotification().getBody());
        }

        // Check if message contains a data payload.
        if (remoteMessage.getData().size() > 0) {
            Log.e(TAG, "Data Payload: " + remoteMessage.getData().toString());

            try {
                JSONObject json = new JSONObject(remoteMessage.getData().toString());
                handleDataMessage(json);
            } catch (Exception e) {
                Log.e(TAG, "Exception: " + e.getMessage());
            }
        }
    }

    private void handleNotification(String message) {
        if (!NotificationUtils.isAppIsInBackground(getApplicationContext())) {
            // app is in foreground, broadcast the push message
            Intent pushNotification = new Intent(Config.PUSH_NOTIFICATION);
            pushNotification.putExtra("message", message);
            LocalBroadcastManager.getInstance(this).sendBroadcast(pushNotification);

            // play notification sound
            NotificationUtils notificationUtils = new NotificationUtils(getApplicationContext());
            notificationUtils.playNotificationSound();
        } else {
            // If the app is in background, firebase itself handles the notification
        }
    }

    private void handleDataMessage(JSONObject json) {
        Log.e(TAG, "push json: " + json.toString());

        try {
            JSONObject data = json.getJSONObject("data");

            String title = data.getString("title");
            String message = data.getString("message");
            boolean isBackground = data.getBoolean("is_background");
            String imageUrl = data.getString("image");
            String timestamp = data.getString("timestamp");
            JSONObject payload = data.getJSONObject("payload");

            Log.e(TAG, "title: " + title);
            Log.e(TAG, "message: " + message);
            Log.e(TAG, "isBackground: " + isBackground);
            Log.e(TAG, "payload: " + payload.toString());
            Log.e(TAG, "imageUrl: " + imageUrl);
            Log.e(TAG, "timestamp: " + timestamp);


            if (!NotificationUtils.isAppIsInBackground(getApplicationContext())) {
                // app is in foreground, broadcast the push message
                Intent pushNotification = new Intent(Config.PUSH_NOTIFICATION);
                pushNotification.putExtra("message", message);
                LocalBroadcastManager.getInstance(this).sendBroadcast(pushNotification);

                // play notification sound
                NotificationUtils notificationUtils = new NotificationUtils(getApplicationContext());
                notificationUtils.playNotificationSound();
            } else {
                // app is in background, show the notification in notification tray
                Intent resultIntent = new Intent(getApplicationContext(), MainActivity.class);
                resultIntent.putExtra("message", message);

                // check for image attachment
                if (TextUtils.isEmpty(imageUrl)) {
                    showNotificationMessage(getApplicationContext(), title, message, timestamp, resultIntent);
                } else {
                    // image is present, show notification with image
                    showNotificationMessageWithBigImage(getApplicationContext(), title, message, timestamp, resultIntent, imageUrl);
                }
            }
        } catch (JSONException e) {
            Log.e(TAG, "Json Exception: " + e.getMessage());
        } catch (Exception e) {
            Log.e(TAG, "Exception: " + e.getMessage());
        }
    }

    /**
     * Showing notification with text only
     */
    private void showNotificationMessage(Context context, String title, String message, String timeStamp, Intent intent) {
        notificationUtils = new NotificationUtils(context);
        intent.setFlags(Intent.FLAG_ACTIVITY_NEW_TASK | Intent.FLAG_ACTIVITY_CLEAR_TASK);
        notificationUtils.showNotificationMessage(title, message, timeStamp, intent);
    }

    /**
     * Showing notification with text and image
     */
    private void showNotificationMessageWithBigImage(Context context, String title, String message, String timeStamp, Intent intent, String imageUrl) {
        notificationUtils = new NotificationUtils(context);
        intent.setFlags(Intent.FLAG_ACTIVITY_NEW_TASK | Intent.FLAG_ACTIVITY_CLEAR_TASK);
        notificationUtils.showNotificationMessage(title, message, timeStamp, intent, imageUrl);
    }
}

4. AndroidManifest.xml

view plainprint?

1. <manifest package="android.developer.solutions.firebasenotification" xmlns:android="http://schemas.android.com/apk/res/android">
2.
3.     <application android:allowbackup="true" android:icon="@mipmap/ic_launcher" android:label="@string/app_name" android:supportsrtl="true" android:theme="@style/AppTheme">
4.         <activity android:label="@string/title_main_activity" android:name=".activity.MainActivity">
5.             <intent-filter>
6.                 <action android:name="android.intent.action.MAIN">
7.
8.                 <category android:name="android.intent.category.LAUNCHER">
9.             </category></action></intent-filter>
10.         </activity>
11.
12.         <!-- Firebase Notifications -->
13.         <service android:name=".service.MyFirebaseMessagingService">
14.             <intent-filter>
15.                 <action android:name="com.google.firebase.MESSAGING_EVENT">
16.             </action></intent-filter>
17.         </service>
18.
19.         <service android:name=".service.MyFirebaseInstanceIDService">
20.             <intent-filter>
21.                 <action android:name="com.google.firebase.INSTANCE_ID_EVENT">
22.             </action></intent-filter>
23.         </service>
24.         <!-- ./Firebase Notifications -->
25.     </application>
26.
27. </manifest>

Download code from here

Hope you like this...
Enjoy Coding..... :)
